Portable Handy Model

1 INSECTICIDE OUT PUT : 10 TO 30 Ltr Oil base Formulation per Fule
2 HEATING PRINCIPLE : Pulse jet engine 80 to 85 Pulse per Second
3 FOG TYPE : Low tempreture without Flamelss
4 FOG PARTICAL SIZE : Controllable from 0.5 to 75 Micron
5 FUEL : Petrol
6 FUEL TANK CAPACITY : 1Ltr
7 INSETICIDE SOLUTION TANK : 5 Ltr
8 CAPACITY : 4 Ltr
9 STARTER : Battry cells Self Starter, Electric, Manual
10 WEIGHT : Empty 10 Kg, Filled 14 kg
11 DIMENSONS : L 125cm , W 25cm, H 35cm
12 VOLT SUPPLY FOR THE IGNITION COIL
13 CHEMICAL TANK MATERIAL
14 FULE TANK MATERIAL

1 The Machine runs on petrol. so always start and stop the machine in the open
2 Do not touch the protective tubing and the out let tube while the machine is Functioning as that may
cause burn injuries.
3 Do not start the machine immediately after use in a close place. allow it to cool sufficiently in the open air.
4 Direct the fog down wind. away from the operator.
5 Insecticide/pesticide formulation should be used under expert advice for best result.
6 Take care of loose electric contacts when indoor Fogging.
7 Fogging should be early in the morning or late in the evening.
8 Clean the air intake valve, particularly the diaphragm and the combustion tube, before storing every
day if used daily.

1 Multi fog Machine is a super performance portable fogging machine. effective, Quick, very efficient and
highly economical, safe in use and easy to operate.
2 Fine Fog particles reach pests on leaf side underneath and insects in cracks.
3 Dosage : Depend upon the area to be treated Toxicity: Free of toxic exhaust fumes, therefore no
danger of using it indoors. protects your health because operator moves away from fog..
4 Warning : The information contained in the pamphlet is true and accurate to the best of
our knowledge. as such we offer no guarantee and cannot accept any responsibility
for operations because it I not under our direction control.
